Installing a Granatelli 1g Suspension Package Into a 5G Camaro

By Joey Granatelli1 min read

In October 2013, writer Rick Seitz followed a Granatelli Motor Sports 1G Suspension Bracing Package install on a fifth-generation Camaro, with J.R. Granatelli at the shop for the work. The story, "Installing a Granatelli 1g Suspension Package Into a 5G Camaro," was published on October 9, 2013 and is now hosted by LSX Magazine.

What the Package Includes

The kit ties the Camaro's subframes together to cut flex in the unibody. According to the article, it combines five parts that Granatelli Motor Sports also sells separately:

  • Front Subframe Connector Kit (PN 500071)
  • K-Member Support Bracket (PN 500072)
  • Butterfly Subframe Connector Kit (PN 500073)
  • Rear Subframe Connector Kit (PN 500074)
  • G-Load Brace (PN 500075)

The piece reports that the parts are made from DOM carbon steel, TIG welded and developed in-house. The car also received rear lower control arms (PN 500058) and front and rear sway bar end links, which are sold apart from the 1G kit. The article credits the control arms with fighting wheel hop compared with the factory stamped steel arms.

The Test Car

The subject was Blake Adams' 2010 Camaro RS/SS with an L99 and a six-speed automatic. Adams road races in Southern California, yet his suspension was still stock. The install took place at Cunningham Motorsports, and J.R. Granatelli helped with some of the wrenching. According to the story, he told the writer that the chassis is stiff enough with the kit that bigger sway bars are not needed, and that adding them could hurt both handling and ride.

Fitment Notes

The car's long-tube headers hung low enough to block the brace. The shop built a pair of spacers about 2 1/4 inches tall to clear them, and the article suggests owners with long tubes plan for the same. J.R. Granatelli explained the bolt-together design this way: "We designed the kit to bolt together easily, for fast installation and the ability for removal when necessary." That means no welding if the engine or transmission ever has to come out.

The Result

The control arms swapped in with just two bolts per side, plus some bushing lube to press them into place. After everything was torqued, the test drive turned up no squeaks or rattles, according to the article.
