J.R. Granatelli’s 700-Plus-HP Trailblazer SS

By Joey Granatelli1 min read

Chevy Hardcore profiled J.R. Granatelli's supercharged Chevrolet Trailblazer SS in a feature dated June 29, 2010. The story also appears in the archive of sister site Street Muscle. J.R. told the magazine he had owned both a Syclone and a Typhoon, and that from the day he bought the Trailblazer, because it shared the Corvette's engine, he wanted to turn it into a modern-day Typhoon.

420 Cubic Inches and a Magnuson Blower

According to the article, the engine came out when the truck had just 300 miles on it. The LS2 was enlarged to 420 cubic inches (6.8L) with an overbore and a 4.25-inch stroke crank, then topped with Trick Flow TFS-LS2 heads and a Magnuson 122 supercharger running 10 psi. Kooks 1 7/8-inch headers feed a Granatelli 3-inch header-back exhaust. For tuning, J.R. started with a Granatelli mass airflow sensor, and the stock ECU was tuned with EFI Live.

725 Horsepower on the Dyno

The machine work and assembly were done in-house at Granatelli Motor Sports. The engine then went to Duttweiler Performance for an engine dyno session, where the article reports 725 hp and 775 lb-ft, close to double the factory figures.

Drivetrain, Suspension and Brakes

  • TCI strengthened the 4L70E with new clutches and gears and supplied a Street Fire converter with a 2,500 rpm stall.
  • The transfer case stayed stock; J.R. said he had been told it holds up to about 750 hp.
  • A Granatelli Motor Sports lower control arm package works with the stock rear air bags, along with an upgraded panhard bar.
  • SSBC brakes measure 13 inches up front and 11 inches in back, with IForged wheels sized 8x20 front and 9x20 rear.

Still a Real Truck

"This truck is still 100% able to drive on the street with ease," J.R. told the magazine. He said it handles grocery runs and tows his 24-foot boat. At the track it ran 12.20 at 123 mph in the rain, then a best of 11.71 at 129 mph with a 1.55-second 60-foot time.

Plans for More

J.R. described plans for a TVS-style blower mounted farther forward on its own belt, with boost raised to around 15 psi in hopes of running in the 10.90s. He also planned water/methanol injection and 100 octane fuel.

Read the full article: the original Chevy Hardcore story (June 29, 2010) no longer appears to be online, so we cannot link to it.
