If you're building a turbocharged vehicle, two of the most important boost-control components are the wastegate and the blow-off valve (BOV). Both deal with pressure in a forced-induction system, but they perform two completely different jobs. Understanding the difference can help you build a turbo system with better boost control, faster response and improved reliability.

Granatelli Motor Sports offers a range of external turbo wastegates and turbo system accessories and blow-off valves for street, street/strip and high-horsepower racing applications.

What Does a Wastegate Do?

A turbo wastegate controls the amount of exhaust energy that reaches the turbocharger's turbine. As exhaust gases leave the engine, they spin the turbine wheel. The more energy reaching the turbine, the faster the turbocharger can spin and the more boost it can potentially produce. The wastegate regulates this process by opening and allowing some exhaust gas to bypass the turbine. This helps maintain the desired boost pressure instead of allowing turbo speed and boost to continue climbing.

• More exhaust sent to the turbine = more boost
• Less exhaust to the turbine = less boost

When the wastegate opens and “bleeds off” excess exhaust energy, it lowers boost. In simple terms: the wastegate controls boost from the exhaust side of the turbo system.

Main Benefits of a Wastegate

Boost Control

Limits maximum boost pressure, stabilizes boost, and prevents dangerous overboost conditions. Without it, boost can climb uncontrollably with RPM and load.

Engine Protection

Helps protect the engine from detonation, excessive cylinder pressure, lean conditions, overheating, and catastrophic failure.

Turbocharger Protection

Helps prevent turbo overspeed. Exceeding safe shaft speed can damage bearings and wheels.

Improved Power Management

Lets tuners shape boost curves, torque delivery, traction, and drivability. This is important for drag racing, road racing, and high-horsepower street cars.

Better Efficiency

A properly sized wastegate reduces pumping losses, stabilizes turbine speed, and improves thermal management for repeatable power and reliability.

Internal vs. External Wastegates

An internal wastegate is built into the turbocharger housing. An external wastegate is a separate valve installed in the exhaust system, mounted on the exhaust manifold or turbo piping, rather than being built directly into the turbocharger. External wastegates are common on custom turbo systems because they allow the builder more flexibility with:

• Wastegate size
• Wastegate placement
• Exhaust bypass flow
• Boost-control strategy
• Turbo manifold design

	Internal Wastegate	External Wastegate
Benefits	Compact, often less expensive, quieter, OEM-friendly	Superior boost control, higher flow capability, better high-RPM control
Drawbacks	Limited flow capacity and less precise control at higher power	Mostly packaging and noise (especially with a screamer pipe)
Commonly Used On	Factory turbo cars and entry-level low-to-moderate power builds	Racing and serious aftermarket forced-induction builds

The “Wastegate Sound”

The screaming sound you hear on some race cars often comes from an external wastegate dumping exhaust to atmosphere through a screamer pipe. That sound is excess exhaust energy being bypassed.

Why External Wastegate Size Matters

An external wastegate must be capable of bypassing enough exhaust flow to control the turbocharger. The proper size depends on the entire engine and turbo combination. Important factors include:

• Engine displacement
• Turbocharger size
• Horsepower level
• Single-turbo or twin-turbo configuration
• Desired boost pressure
• Exhaust manifold design
• Wastegate location
• Exhaust flow

If the wastegate cannot bypass enough exhaust, boost pressure may continue increasing above the intended target. This is commonly called boost creep. Wastegate size, placement, exhaust-manifold design and exhaust flow can all influence boost control.

Granatelli 44mm, 50mm and 60mm External Wastegates

Granatelli Motor Sports offers multiple external wastegate sizes so builders can select the proper boost-control solution for their turbo combination.

Granatelli 44mm Piston-Actuated External Wastegate – 540261

The Granatelli 44mm piston-actuated external wastegate provides a compact option for turbo systems where engine-bay space and packaging are important. It uses piston actuation instead of a traditional flexible diaphragm and features V-band inlet and outlet connections. View the Granatelli 44mm Piston Wastegate – 540261

Granatelli 50mm Piston-Actuated External Wastegate – 540203

For applications requiring additional exhaust bypass capacity, the Granatelli 50mm piston wastegate provides increased flow while retaining a piston-actuated design. The 50mm wastegate is designed for demanding street, street/strip, drag racing and performance turbo applications. View the Granatelli 50mm Piston Wastegate – 540203

Granatelli 60mm Piston-Actuated External Wastegate – 540260

Large-frame turbochargers and high-exhaust-flow engine combinations may require even greater wastegate capacity. The Granatelli 60mm piston-actuated external wastegate is designed for serious turbo systems requiring substantial exhaust bypass flow and consistent boost control. Its large 60mm valve, piston-actuated design and V-band mounting make it well suited for high-horsepower turbo cars, drag racing applications and other high-flow combinations.

View the Granatelli 60mm Piston Wastegate – 540260

Piston Wastegate vs. Diaphragm Wastegate

Traditional external wastegates commonly use a flexible diaphragm to control valve movement. Granatelli also offers piston-actuated external wastegates. Instead of relying on a traditional diaphragm, the piston series uses mechanical piston actuation to regulate exhaust bypass flow. Granatelli also offers water-cooled diaphragm wastegates for builders who prefer a traditional diaphragm design with additional heat management around the actuator.

Granatelli Water-Cooled Wastegates

Wastegates operate extremely close to turbochargers, exhaust manifolds and other high-temperature components. Managing that heat can become important on tightly packaged and competition-oriented turbo systems. A water-cooled wastegate incorporates coolant passages around the actuator area to help manage temperature. Granatelli Motor Sports offers water-cooled diaphragm wastegates designed to help manage actuator temperature in demanding turbocharged applications.

Granatelli 44mm Water-Cooled Wastegate – 540244

The Granatelli 44mm water-cooled external wastegate combines compact packaging with a water-cooled diaphragm actuator, billet aluminum top and V-band mounting. View the Granatelli 44mm Water-Cooled Wastegate – 540244

Granatelli 50mm Water-Cooled Wastegate – 540202

The Granatelli 50mm water-cooled wastegate increases exhaust bypass capacity while using a water-cooled diaphragm housing to help manage heat around the actuator. View the Granatelli 50mm Water-Cooled Wastegate – 540202

What Does a Blow-Off Valve Do?

While the wastegate controls boost from the exhaust side of the turbocharger, a blow-off valve controls compressed air on the intake side. Under boost, the turbocharger compressor forces air through the charge piping, intercooler and toward the throttle body. When the driver suddenly lifts off the throttle, the throttle blade closes while the turbocharger is still spinning. The compressed air that was moving toward the engine suddenly has nowhere to go.

A blow-off valve opens and gives that trapped pressurized air an escape path. This helps reduce compressor surge and helps protect the turbocharger. A BOV also helps maintain responsiveness when you lift off the throttle, and it can protect a supercharger as well as a turbocharger.

What Is Turbo Compressor Surge?

Compressor surge can occur when airflow through the turbocharger compressor becomes unstable. One situation where this can happen is when pressurized air encounters a closed throttle and begins moving back toward the turbocharger compressor, where it can slam back against the compressor wheel. Instead of allowing that pressure wave to push back against the compressor wheel, a properly sized BOV can release the excess pressure when the throttle closes. This becomes increasingly important as turbocharger size, boost pressure and airflow increase.

Controlling compressor surge:

• Reduces stress on turbo/blower bearings
• Helps prevent premature wear or damage
• Improves throttle transitions and shift recovery

Performance Benefits of a Proper BOV

• Faster response between shifts: less lag, smoother power delivery
• Improved drivability: smoother transitions during throttle changes
• Reduced surge noise: less “flutter/chirp/turkey gobble”
• Stabilized compressor operation: helps maintain efficiency

Atmospheric vs. Recirculating (Diverter) Valves

Atmospheric BOV

Vents air to atmosphere for the loud “whoosh.” Popular on aftermarket performance builds. On MAF-based cars, see the FAQ below before choosing an atmospheric valve.

Recirculating (Diverter) Valve

Routes air back into the intake system. Quieter, OEM-preferred, and typically better for MAF-based drivability and emissions compliance.

Granatelli 64mm Anaconda Blow-Off Valve – 540199

For serious forced-induction applications, Granatelli Motor Sports developed the 64mm Anaconda High-Flow Blow-Off Valve. The Anaconda is designed for high-horsepower turbocharged and centrifugal-supercharged combinations that require substantial airflow capacity and rapid pressure relief. Key features include:

• Massive 64mm high-flow valve design
• Billet 6061 aluminum construction
• Black anodized finish
• Adjustable diaphragm-over-piston design
• Dual 1/8-inch NPT reference ports
• High-flow pressure relief
• Designed to help reduce compressor surge
• Suitable for turbocharged and centrifugal-supercharged applications

The large 64mm valve provides the airflow capacity needed for serious forced-induction systems where a smaller blow-off valve may become restrictive. View the Granatelli 64mm Anaconda Blow-Off Valve – 540199

Granatelli 50mm Viper Series Blow-Off Valve – 540198

The Granatelli 540198 Viper Series is a 50mm high-flow vent-to-atmosphere blow-off valve. Its externally adjustable spring preload allows the BOV response to be tailored to the vacuum and boost characteristics of the individual turbo system. Key Viper Series specifications include:

• 50mm valve size
• Adjustable spring preload
• Vent-to-atmosphere discharge
• Billet aluminum construction
• Universal custom turbo application

Cold-Side Pressure Relief on Centrifugal Superchargers

Centrifugal superchargers are crank-driven, so you can’t control impeller speed like a turbo does with a wastegate. Cold-side pressure relief (like the Anaconda concept) can help cap/flatten boost curves, improve traction, and reduce overboost risk while allowing more aggressive pulley ratios.

• Allows peak boost sooner in the RPM range (depending on setup)
• Helps prevent top-end boost runaway
• Can improve consistency and reduce engine stress in racing

Why Blow-Off Valve Size Matters

A blow-off valve must be capable of releasing the volume of compressed air produced by the turbo system. As turbo size, boost pressure and horsepower increase, the amount of air that may need to be released during throttle lift also increases. A high-flow blow-off valve can be especially valuable on:

• Large-frame turbochargers
• Twin-turbo engines
• High-boost combinations
• Large-displacement engines
• Drag racing vehicles
• Roll-racing cars
• High-horsepower street cars
• Centrifugal-supercharged vehicles

Wastegate vs. Blow-Off Valve: What's the Difference?

Component	Wastegate	Blow-Off Valve
Location	Exhaust side	Intake / charge side
Main Job	Controls exhaust flow around the turbine	Releases trapped compressed air
When It Operates	To regulate turbo boost	Primarily during throttle lift
Helps Control	Turbo speed and boost pressure	Compressor surge and trapped charge pressure

Do You Need Both a Wastegate and a Blow-Off Valve?

On most performance turbo systems, yes. A wastegate and blow-off valve cannot replace one another because they perform completely different jobs. The wastegate controls how much exhaust energy drives the turbocharger, while the blow-off valve manages compressed air when the throttle closes. Using properly sized components on both sides of the turbo system helps improve boost control, pressure management and overall system consistency.

What Size Wastegate Do I Need?

There is no universal wastegate size that is correct for every turbo build. Wastegate sizing depends on the complete combination. Consider:

• Engine displacement
• Turbocharger size
• Desired boost level
• Exhaust manifold configuration
• Wastegate placement
• Single or twin wastegates
• Target horsepower
• Exhaust flow

Correct wastegate sizing and placement are essential for consistent boost control.

What Size Blow-Off Valve Do I Need?

BOV sizing also depends on the amount of airflow the forced-induction system is moving. Important factors include:

• Turbocharger size
• Boost pressure
• Engine displacement
• Horsepower level
• Charge-pipe diameter
• Charge-system volume
• Single or twin turbo configuration

A moderate street turbo system may not require the same valve capacity as a large-frame turbo or high-horsepower twin-turbo combination. Granatelli Motor Sports offers 50mm BOV options, and for applications moving substantial volumes of compressed air, the Granatelli 64mm Anaconda BOV provides a high-flow option designed specifically for serious forced-induction applications.

Building a Better Turbo System

The turbocharger may receive most of the attention when planning a boosted engine, but controlling the turbocharger is just as important as selecting it. A complete turbo system should consider:

• Turbocharger sizing
• Wastegate sizing
• Wastegate location
• Wastegate spring pressure
• Boost-control strategy
• Blow-off valve sizing
• BOV location
• Charge-pipe diameter
• Intercooler size
• Exhaust flow
• Engine displacement
• Horsepower target

Matching these components correctly can produce a turbo system that is easier to control, more responsive and better suited to the intended horsepower level.

Wastegate & Blow-Off Valve FAQ

Does a Wastegate Control Boost?

Yes. The wastegate is one of the primary components responsible for controlling boost pressure on a turbocharged engine.

What Do Wastegate Springs Do?

The wastegate spring establishes the mechanical base boost pressure. Spring options vary by kit; check the instructions included with your wastegate for the springs supplied and their boost ratings. A boost controller can then be incorporated into the system when additional boost control is required.

Can I Run More Boost Than the Wastegate Spring?

Yes, depending on the boost-control system. Electronic or manual boost-control systems can be used to command additional boost above the base pressure set by the spring. Boost settings should always be appropriate for the engine, fuel system, turbocharger and tune.

Is a Bigger Wastegate Always Better?

No. A larger wastegate can bypass more exhaust, but a larger engine or turbocharger does not automatically mean that the largest possible wastegate is the correct choice. The goal is to select a wastegate that provides the amount of exhaust bypass flow required for the specific turbo system.

Does Wastegate Location Matter?

Yes. A wastegate needs to receive enough exhaust flow to effectively control the turbocharger. Poor wastegate placement can make boost control more difficult even if the wastegate itself is large enough. Wastegate placement should be considered during the design of the turbo manifold rather than treated as an afterthought.

What Does BOV Stand For?

BOV stands for Blow-Off Valve. The terms BOV, turbo BOV and blow-off valve are commonly used interchangeably.

Does a Blow-Off Valve Add Horsepower?

A blow-off valve does not directly create horsepower. Its purpose is pressure management. A properly selected BOV helps release trapped compressed air when the throttle closes.

Is Turbo Flutter the Same as a Blow-Off Valve Sound?

Not necessarily. A blow-off valve sound is created by compressed air being released through the BOV. Flutter can be associated with pressure interacting with the compressor when the throttle closes. Because different turbo systems behave differently, sound alone should not be used to determine whether a BOV is operating correctly.

Is a Bigger Blow-Off Valve Better?

Not automatically. A larger BOV can provide greater airflow capacity, but the correct valve should be matched to the airflow and pressure requirements of the forced-induction system. A high-horsepower turbo combination may require more pressure-relief capacity than a mild street turbo system.

What Does Vent-to-Atmosphere Mean?

A vent-to-atmosphere BOV releases compressed air directly outside the charge system when the valve opens. This creates the distinctive pressure-release sound commonly associated with performance turbo vehicles.

Can I Use an Atmospheric BOV on a MAF Vehicle?

It depends on the engine-management strategy. On some mass-airflow-metered vehicles, the engine-management system has already measured the air before the BOV releases it. Venting that measured air into the atmosphere can affect drivability on some applications and can cause rich conditions if not tuned correctly. Before installing an atmospheric BOV, verify that the vehicle's engine-management configuration is compatible with atmospheric venting.

Where Should a Blow-Off Valve Be Installed?

A blow-off valve is installed in the turbocharger charge piping. The ideal location depends on:

• Turbocharger location
• Intercooler placement
• Throttle-body location
• Charge-pipe design
• Available mounting space
• Vacuum reference routing

How Do You Adjust an Adjustable BOV?

An adjustable BOV should be set according to the vacuum and boost characteristics of the specific engine. On the Granatelli Viper Series, the externally adjustable spring preload allows the installer to fine-tune valve response. The goal is to have the valve remain closed when it should be sealed while still responding properly when pressure needs to be released.

Can a BOV Control Boost Pressure?

A BOV is not intended to replace the wastegate as the primary method of controlling turbo boost. The wastegate controls how much exhaust energy drives the turbocharger. The BOV releases charge pressure during throttle events.

What Should I Upgrade First: Wastegate or BOV?

That depends on the problem you are trying to solve. If you are having trouble controlling boost pressure, the wastegate system, wastegate sizing, location and boost-control strategy should be evaluated. If you need additional pressure-relief capacity when the throttle closes, the BOV system should be evaluated.

Do Wastegates and BOVs Need Maintenance?

Like any component exposed to heat, pressure and repeated operation, wastegates and blow-off valves should be inspected periodically. Check:

• Mounting hardware
• V-band connections
• Vacuum and boost-reference lines
• Hoses and fittings
• Signs of leaks
• Valve movement
• Heat damage

Why Choose Granatelli Motor Sports Turbo Components?

Granatelli Motor Sports offers multiple turbo boost-control solutions for everything from street-driven performance cars to high-horsepower race vehicles. The Granatelli turbo-control lineup includes:

• 44mm piston-actuated external wastegates (540261)
• 50mm piston-actuated external wastegates (540203)
• 60mm piston-actuated external wastegates (540260)
• 44mm water-cooled diaphragm wastegates (540244)
• 50mm water-cooled diaphragm wastegates (540202)
• Granatelli 60mm Water-Cooled Diaphragm External Turbo Wastegate with V-Band – 540259
• 64mm Anaconda high-flow blow-off valve (540199)
• Granatelli 50mm Viper Series Adjustable Atmospheric Turbo Blow-Off Valve – 540198
• Granatelli 50mm Adjustable Turbo Blow-Off Valve with V-Band – 540200
• Granatelli 50mm Ultra High Flow Turbo Blow-Off Valve – 540201
• V-band flanges and clamps
• Turbo adapters
• Boost-control accessories

The Bottom Line: Wastegate vs. BOV

A wastegate and blow-off valve both help manage a turbocharged engine, but they control completely different parts of the system. Wastegate = controls exhaust energy and turbo boost. Blow-off valve = releases compressed intake pressure when the throttle closes. For a properly designed high-performance turbo system, both components need to be correctly sized, installed and matched to the engine and turbocharger combination.

Granatelli Motor Sports offers piston-actuated wastegates, water-cooled diaphragm wastegates and high-flow blow-off valves designed for serious street and racing applications.

Shop Granatelli Wastegates & Blow-Off Valves

Ready to upgrade your turbo boost-control system? Control the boost. Control the pressure. Build the turbo system the right way. Shop Granatelli External Wastegates Shop the Granatelli 64mm Anaconda Blow-Off Valve Shop Granatelli Turbo System Accessories

---

Written by JoJo Granatelli — third generation at Granatelli Motor Sports in Oxnard, California, and the one who drives what the company builds. He set a quarter-mile record of 7.06 seconds at 157 mph at Famoso Dragstrip in August 2026. More about JoJo.
